LM78L09 Pinout, Equivalent, Applications, Features

LM78L09 is a positive voltage regulator available in TO-92 and other packages. This article describes LM78L09 pinout, equivalent, applications, features and other important info about this IC.

Advertisements

LM78L09 Pinout, Equivalent, Applications, Features

Advertisements



LM78L09 IC Features / Technical Specifications

  • Available in TO-92 and other small packages
  • Can deliver max output of 100mA
  • Short circuit protection feature
  • Thermal shutdown feature
  • Small size and low cost
  • Reliable to use in commercial equipment
  • Accurate and stable 9V output
  • Standby current only 3mA to 5mA
  • Maximum input voltage is 35V DC



LM78L09 Description

LM78L09 is a 9V fixed voltage regulator IC of LM78Lxx series. This series contains small size fixed voltage regulator of different voltages such as 5.0V, 6.2V, 8.2V, 9.0V, 12V, 15V with maximum output current of 0.1A or 100mA. The IC is available in TO-92 and other small packages. The output voltage of the IC can be checked by the last two digits written after “LM78L”. LM78Lxx is a series of positive voltage regulators but there is also same negative voltage regulators series is available that starts from “LM79L”.

The input voltage supply range of the IC is wide and you can provide minimum input voltage from 12V to 35V DC with 150mA to 200mA input current. One thing should be kept in mind when designing the circuit and using LM78L09 voltage regulator that the input voltage should be atleast 3V higher than the output voltage to get an accurate and stable 9V output.

LM78L09 IC has many built features such as short circuit protection, over heat shutdown, safe area protection that makes this IC internally damage proof and reliable to use in commercial equipment.



Advertisements



Applications

Voltage step down applications

DC to DC converter applications

Power supply applications

Battery Chargers

Microcontroller circuits applications

Computer and telecommunication applications



Replacement and Equivalent / Other Part Numbers

78L09ACZ, TS78L09CT, if somehow you are unable to find the substitute ICs then you can also use LM317LZ and get fixed 9V output by using two external resistors.



9V 100mA Power Supply Using LM78L09 IC

The figure shows a 9V regulated power supply Using LM78L09 IC.



How to Safely Long Run in a Circuit

To get long term performance from LM78L09 IC it is suggested to use this IC atleast 20% below from its maximum ratings. The maximum output current is 100mA therefore do not drive load of more than 80mA, the maximum input voltage is 35V DC for safety do not provide more than 28V to 30V DC and always operate the IC in temperature above 0 degree centigrade and below 125 degree centigrade. The storage temperature of the IC is from -65 degree centigrade to +150 degree centigrade.



Datasheet

To Download the datasheet just copy and paste the below link in your browser.

https://datasheetspdf.com/pdf-file/54107/NationalSemiconductor/LM78L09/1
