LM741 IC Pinout, Features, Applications, Equivalents & More

LM741 is a quite popular general purpose op amp IC, here we are going to discuss LM741 pinout, features, applications, equivalents, description and other useful and interesting information about this IC.



LM741 is a quite popular general purpose op amp IC, here we are going to discuss LM741 pinout, features, applications, equivalents, description and other useful and interesting information about this IC.



LM741 IC Features / Technical Specifications:

  • This IC contains overload protection circuitry at the input & output.
  • The IC also contains protection circuitry for short circuit.
  • The internal circuitry is designed to stay stable at different temperatures.
  • Can be operated from wide supply range.
  • It can be operated with both single and dual supply.
  • It consumes low power.
  • High gain
  • It is direct replacement for lm201, MC1439, 748.
  • The internal circuitry is also latch up protected.
  • The operated current is from 1.7 to 2.8mA.
  • Latch up free



LM741 Pin Configuration:

Pin#Pin NamePin Description
1Offset NullThis pin is used to get rid of offset voltage & balance the input voltage.
2Inverting InputInverting Input of the IC's
3Non Inverting Input Non Inverting Input of the IC.
4V-Ground / Negative Supply Pin.
5Offset NullThis pin is used to get rid of offset voltage & balance the input voltage.
6OutputOutput pin of the IC
7V+Positive Supply pin of the IC.
8NCNC Means Not Connected Pin.



LM741 Description:

LM741 is an operational amplifier IC packed with many features. The IC is available in many different packages. The number of transistors used in the internal circuitry of the IC is 20. The IC can be used in wide range of analog projects. Its feature like high gain, low current consumption and wide supply voltage makes it ideal to use in battery operated circuits. Moreover the IC is also overload protected from both sides i.e. input and output, this features saves the internal circuitry of the IC from damage by overload.



Applications:

It can be used in Comparators

DC amplifiers can be built using this IC

It can also be used in summing amplifiers

Can be used in multi vibrator circuits

Active filters can be built using this IC



Replacement / Equivalent / Other Part Numbers:

MC1439, LM748, LM709C, LM201



Application Circuits :

There are two circuits show below using the LM741 IC. This first circuit is a light sensor and the second is dark sensor circuit.

Light Sensor Circuit

This light sensor circuit shown below is using LM741 IC as a multivibrator in the circuit. the 120K variable resistor is used to adjust the sensitivity or activation point of the LED. The circuit is using an LDR sensor to sense light. The LED will become activate when the light level on the LDR will reach the preset level set by the 120K variable resistor. The operating voltage of the is 9V DC.

LM741 light sensor circuit



Dark Sensor Circuit

As in the above circuit the lm741 is also used in this dark sensor circuit in astable multivibrator mode but this time, for detecting darkness the middle pin of the variable resistor is connected with pin three / non inverting input of the IC. Now the LED will become activated when the level or darkness on the surface of the LDR will reach at the preset level set by the 120K variable resistor in the circuit. The power supply of this circuit is also 9V.

LM741 dark sensor circuit



How to Get Good and Stable Long Term Performance from this IC:

To get long term good performance from ICs it is suggested to always stays under its maximum ratings. To safely run lm741 IC for long term in your projects / devices do not apply load more than 500mW. Do not apply more than ±22V to the chip and the minimum operating voltage should be ±10V.For good performance always decouple power supplies by using a 0.1uF capacitor and place it as near as possible to the IC in your circuit. Always store and use the IC under -55 centigrade and +125 centigrade.
