2N3439 Transistor Pinout, Specs, Equivalents, Features, Applications and Other Useful Info

2N3439 is an NPN metal case transistor manufactured in TO-39 metal package. The post describes 2N3439 transistor pinout, specs, equivalents, features, applications and other useful info.

Advertisements

2N3439 Transistor Pinout, Equivalent, Uses, Features and More

Advertisements



Features / Technical Specifications:

  • Package Type: TO-39
  • Transistor Type: NPN
  • Max Collector Current(IC): 1A or 1000mA
  • Max Collector-Emitter Voltage (VCE): 350V
  • Max Collector-Base Voltage (VCE): 450V
  • Max Emitter-Base Voltage (VEBO): 7V
  • Max Collector Dissipation (Pc): 10 Watt
  • Max Transition Frequency (fT):  15 MHz
  • Minimum & Maximum DC Current Gain (hFE): 30 to 160
  • Max Storage, Operating & Junction temperature range: -65 to +200 Centigrade



Replacement and Equivalent:

2N5279, 40390



2N3439 Transistor Explained / Description:

2N3439 is a TO-39 metal can package transistor that is built to use in commercial and home equipment and appliances. The transistor contains many features such as high collector to emitter voltage of upto 350V. This high collector to emitter voltage makes it suitable to be used in many applications such as inverters, regulators etc.

The transistor is having quite interesting specs such as collector to emitter voltage is 350V, collector to base voltage is 450V, max emitter to base voltage is 7V, max collector current is 1A, and total device dissipation is 5 Watts at 25°C.

The transistor is designed to use in many applications such as low current inverters with high voltage, switching regulators.



Where We Can Use it & How to Use:

2N3439 can be used in many applications. For example, it can be used in circuits that require high voltage. Other than that it can also be used in amplifier circuits. Moreover, it is not only limited to these uses and can also be used in other applications such as switching, etc.



Applications:

Audio Amplifiers such as guitars and other audio amplifiers

Power Supplies

Lighting Circuits

X-ray machines

Switch Mode Power Supply

Defibrillators

High Voltage Signal Handling Devices

Switching Loads under 1000mA



Safe Operating Guidelines / Absolute Maximum Ratings:

Here are the safe operating guidelines to get good stable and long term performance with this transistor.

  • Always use the transistor 20% below its absolute maximum ratings. Using the transistor to its absolute maximum rating may result in damaging the transistor or weakening its performance.
  • The max collector current is 1000mA so do not drive load of more than 800mA.
  • The max collector to emitter voltage is 350V therefore the driven load should be under 280V.
  • A proper and suitable heatsink is essential to use with the transistor.
  • Store or operate the transistor at temperatures between -65°C and +200 °C.



Datasheet:

To Download the datasheet just copy and paste the below link into your browser.

https://z3d9b7u8.stackpathcdn.com/pdf-down/2/N/3/2N3440_STMicroelectronics.pdf
