IRFP250 Transistor Pinout, Equivalent, Uses, Features, Applications and More

This post describes IRFP250 transistor pinout, equivalent, uses, features, applications and other important information about this power MOSFET transistor.

Features / Technical Specifications:

• Package Type: TO-247, TO-3P
• Transistor Type: N Channel
• Max Voltage Applied From Drain to Source: 200V
• Max Gate to Source Voltage Should Be: ±20V
• Max Continues Drain Current is : 30A
• Max Pulsed Drain Current is: 130A
• Max Power Dissipation is: 180W
• Max Drain to Source Resistance in ON State (RDS on): 085mΩ
• Max Storage & Operating temperature Should Be: -55 to +175 Centigrade

Replacement and Equivalent:

IRFP260, STW38NB20, MTW32N20E

IRFP250 Transistor Explained / Description:

IRFP250 is an N channel MOSFET or power field effect transistor available in TO-247 and some manufacturers also make it in TO-3P transistor package. The transistor has many features such as low drain to source on resistance only 0.085 Ohm, very fast switching speed of Nanosecond which makes it ideal to use in applications where high speed switching is required, High input impedance, it is simple to drive due to which it can be operated directly from microcontroller or ICs outputs, voltage control, temperature stable etc. All these and other features makes this device reliable to use for commercial purposes.

Regarding to the specifications of the transistor the maximum drain to source voltage is 200V, maximum continuous drain current is 30A, maximum power dissipation is 180W. The primary applications of the transistor are high speed switching applications, UPS systems, AC to DC converters, DC to DC converters, telecommunication applications, lighting equipment etc.

Where We Can Use it & How to Use:

As mentioned above IRFP250 MOSFET is primarily designed to use in applications such as UPS, AC to DC and DC to DC converters, lighting equipment etc. but it is not limited to only these uses and can be used for variety of purposes. Moreover it can also be used to build high power audio amplifiers.

Applications:

BMS Circuits

Battery Chargers Circuits

Switch Mode Power Supplies

AC to DC converters

DC to DC converters

Solar Chargers

Solar Power Supplies

Safe Operating Guidelines / Absolute Maximum Ratings:

For long term performance do follow these guidelines in your design or circuit. Do not use the transistor on its absolute maximum ratings and always stay 20% below from its max ratings. The maximum drain to source voltage is 200V therefore do not drive load of more than 160V, the maximum continuous drain current is 33A so do not drive load of more than 24A, use suitable heatsink with the transistor and always store or operate the transistor in temperature above -55°C and below +150 °C.

Datasheet:

To Download the datasheet just copy and paste the below link in your browser.

https://cdn.datasheetspdf.com/pdf-down/I/R/F/IRFP250-Vishay.pdf
