LM7805 Pinout, Equivalent, Datasheet, Applications, Features and More

LM7805 is a fixed output voltage regulator IC. In this post you we are going to discuss about LM7805 pinout, equivalent, datasheet, applications, features and other useful information about this IC.

Advertisements

LM7805 Pinout, Equivalent, Datasheet, Applications, Features and More

Advertisements

LM7805 IC Features / Technical Specifications

  • TO-220 Package
  • The Output current is 1.5 Ampere
  • Instant short circuit shutdown function
  • Instant over heat shutdown function
  • Low cost
  • Reliable to use in commercial devices
  • Accurate and fixed 5V output
  • Max input voltage is 35V DC
  • Low quiescent current only 8mA



LM7805 Description

LM7805 is a 5V output positive voltage regulator IC. It is the IC of LM78xx positive voltage regulator series. It is manufactured in TO-220 and other packages. This IC is quite reliable due to which it is widely used in commercial equipment and educational project. Moreover it is also used by many electronics hobbyists and tinkerers in their projects due to its low cost, easy to use and low external components. The IC has many built in features which make it ideal to use in variety of electronic applications like the 1.5A output current, over load protection function, over heat protection, low quiescent current etc.



Applications

  • Voltage step down
  • Power Supplies
  • Battery Chargers
  • Solar Power Supplies
  • Microcontroller Related Applications
  • Motor Drivers



Replacement and Equivalent / Other Part Numbers

LM340, LM340A and LM1084-5.0 can be used as equivalent of LM7805, if these are not available you can also use an LM317 IC to get fixed 5V output.



How to Safely Long Run in a Circuit

For stable and long term performance it is suggested to not operate load more than 1.5A, always use a suitable heatsink with it, always check pinout before using in your application and do not operate in temperature below 0 degree Celsius and above +125 degree Celsius and always store in temperature above -65 degree Celsius and below +150 degree Celsius.



Datasheet

To Download the datasheet just copy and paste the below link in your browser.

https://pdf1.alldatasheet.com/datasheet-pdf/view/82833/FAIRCHILD/LM7805.html
