IRFZ46N Pinout, Equivalent, Uses, Features and Other Details

In this article we are going to discuss IRFZ46N pinout, equivalent, uses, features and other details about this N-Channel TO-220 package Power MOSFET.

Advertisements

IRFZ46N Pinout, Equivalent, Uses, Features and Other Details

Advertisements



Features / Technical Specifications

  • Package Type: TO-220
  • Transistor Type: N Channel
  • Max Voltage Applied From Drain to Source: 55V
  • Max Gate to Source Voltage Should Be: ±20V
  • Max Continues Drain Current is : 53A
  • Max Pulsed Drain Current is: 180A
  • Max Power Dissipation is: 107W
  • Drain to Source Resistance in ON State (RDS on): 16.5mΩ
  • Max Storage & Operating temperature Should Be: -55 to +175 Centigrade



Replacement and Equivalent

IRFIZ48G, IRFZ10, IRFZ44N, STP55N06, MTP50N06E, RFP50N05, RFP50N06, SSP50N05, SSP50N06, SSS50N06, SSS60N06, STP53N06, STP55N05, STP55N06FI, STP60N05, BUK456-60H, IRFIZ48G.



IRFZ46N MOSFET Explained / Description

IRFZ46N is an N Channel MOSFET available in TO-220 package. This transistor can be used in wide variety of applications. The transistor can drive max load of 53A and 180A in pulse mode. The maximum load voltage is 55V and power dissipation of the transistor is 107 Watt. The transistor features high switching speed which makes it ideal to use in applications where high speed is crucial such UPS applications.

The maximum storage and operating temperature of the device is between -55 to +175 degree Celsius, the soldering temperature limit is 300 centigrade for 10 seconds which means that while soldering this transistor can survive in temperature of 300 degree centigrade but it become burnout from inside or outside if this temperature will continue for more than 10 seconds.

Other than that this transistor can also be used for audio amplification purposes and also in audio amplifier stages.



Advertisements



Where We Can Use it & How to Use

IRF46N can be used in wide variety of general purpose applications for example it can be used in switch mode power supplies, UPS, DC to DC converters etc. Moreover it can also be used for audio amplification purposes. The operating procedure of this MOSFET is same as we use other MOSFETs.



Applications

Switch Mode Power Supplies

Battery Chargers Circuits

Voltage Converters

Solar Chargers and Power Supplies



How to Safely Long Run in a Circuit

To get long life performance with IRFZ46N always use it 20% below from its max ratings. The max continuous drain current of the transistor is 53A therefore do not load of more than 42.4A. The max drain to source voltage is 55V therefore stay under 44V. Place a suitable heatsink with the transistor and always use or store this device in temperature above -55 degree Celsius and below +175 degree Celsius.



Datasheet

To Download the datasheet just copy and paste the below link in your browser.

https://cdn.datasheetspdf.com/MoV/web/viewer.html?file=/pdf-down/I/R/F/IRFZ46N_InternationalRectifier.pdf#zoom=page-width&pagemode=none
