2N5088 Transistor Pinout, Equivalent, Feature, Applications

2N5088 is a general purpose TO-92 packaged transistor, in this post of will find 2N5088 transistor pinout, Equivalent, feature, applications & other information about this transistor.

Advertisements

2N5088 Transistor Pinout, Equivalent, Feature, Applications

Advertisements





Features / Technical Specifications:

  • Package Type: TO-92
  • Transistor Type: NPN
  • Max Collector Current(IC): 100mA
  • Max Collector-Emitter Voltage (VCE): 30V
  • Max Collector-Base Voltage (VCB): 35V
  • Max Emitter-Base Voltage (VEBO): 5V
  • Max Collector Dissipation (Pc): 625 miliWatt
  • Max Transition Frequency (fT): 50 MHz
  • Minimum & Maximum DC Current Gain (hFE): 300 – 900
  • Max Storage & Operating temperature Should Be: -55 to +150 Centigrade



Replacement and Equivalent:

2N5089, SS9014, MPS650, MPS6602 (Pin configuration of these equivalent transistors may different from each other, therefore it is recommended to first confirm pin configuration of the replacement transistor.)



2N5088 Transistor Explained / Description:

2N5088 is a general purpose TO-92 package transistor. It is designed to be used for low noise and high gain amplification purposes and it can also used as a switch. As an amplifier it is capable to amplify many types of low gain signals to high gain with extra noise cuttoff. It can also be used as a separate amplifier at the output of different audio circuits to drive a small 2 to 3 inche speaker. On the other hand when used as a switch it is capable to drive load of 100mA continues and 200mA in peak mode.



Advertisements



Where We Can Use it & How to Use:

2N5088 can be used for many general purpose applications, due to its DC high gain feature it will perform well in audio preamplifiers, audio amplifiers, signal amplifications etc. it can also be used as a switch to drive different loads under 100mA.



Applications:

Switching loads under 100mA

Audio Preamplifiers

Mic Amplifier

Audio Amplifiers and in Their Stages

Sensor Circuits

Darlington Pairs



How to Safely Long Run in a Circuit:

To make this transistor capable to perform long life in your product it is recommended to follow the instructions here. Does not drive load more than 100mA in continuous and 200mA in peak. Do not drive load of more than 30V and always operate or store in temperature above -55 Celsuis and below +150 centigrade.



Datasheet:

To Download the datasheet just copy and paste the below link in your browser.

https://pdf1.alldatasheet.com/datasheet-pdf/view/15086/PHILIPS/2N5088/+0418JUL.hKpRudtyCtGh+/datasheet.pdf
