2SD965 Transistor Pinout, Equivalent, Uses, Features

This article describes all the information about 2SD965 transistor pinout, equivalent, uses, features and other important details about this high current transistor.

Advertisements

2SD965 Transistor Pinout, Equivalent, Uses, Features

Advertisements



Features / Technical Specifications

  • Package Type: TO-92
  • Transistor Type:  NPN
  • Max Collector Current(IC): 5A
  • Max Collector-Emitter Voltage (VCE): 20V
  • Max Collector-Base Voltage (VCB): 40V
  • Max Emitter-Base Voltage (VEBO): 7V
  • Max Collector Dissipation (Pc): 750 miliWatt
  • Max Transition Frequency (fT): 100 MHz
  • Minimum & Maximum DC Current Gain (hFE): 230 – 600
  • Max Storage & Operating temperature Should Be: -55 to +150 Centigrade



Replacement and Equivalent

KSD5041RTA, 2SD966, ECG11, ZTX869, ZTX851, ZTX851STZ, ZTX849STZ, ZTX849



2SD965 Transistor Explained / Description

2SD965 is an NPN BJT transistor manufactured in TO-92 by many components manufacturers and also in other packages by some manufacturers. The transistor is having a very unique feature that makes it special from other general purpose TO-92 transistors. It is designed as a low voltage and high current device thus the collector current of the transistor is upto 5A which makes it ideal to use in wide variety of applications where there is requirement to drive high current loads. The DC current gain of 230 to 600 and collector dissipation of 750mW also makes it ideal to use as an amplifier or preamplifier in many amplification related application. Moreover the 100MHz transition frequency also makes it suitable to use in RF circuits that works under 100 MHz frequencies.



Advertisements



Where We Can Use it & How to Use

The 2SD965 transistor can be used in wide variety of general purpose switching and amplification applications. As a switch it can drive load of upto 5A therefore you can drive many loads in electronic circuits such as high current relays, high power LEDs, high power transistors etc. However as an amplifier it can be used to amplify many type of small signals in electronics and can also be used as an audio preamplifier and amplifier.



Applications

Sensor and detector

Radio Frequency Applications

Audio amplifier

Audio preamplifier

Switching circuit to drive upto 5A load



How to Get Long Life Performance in a Circuit

To get long term performance from any component we suggest not using a component on its maximum ratings and always use it atleast 20% below from its max ratings. The max collector current of this transistor is 5A therefore do not drive load of more than 4A. The max collector to emitter voltage is 20V therefore stay under 16V and whether it is in use or storage do not expose it to temperature below -55 centigrade and above +150 centigrade.



Datasheet

To Download the datasheet just copy and paste the below link in your browser.

https://cdn.datasheetspdf.com/pdf-down/2/S/D/2SD965_PanasonicSemiconductor.pdf
